MINNEAPOLIS · CHIMNEY RELINING

Chimney Relining in Minneapolis — When the Liner Needs to Go

Replacement liner sized to the appliance — not the old clay tile dimensions. An oversized liner on a modern gas appliance creates the same condensation problem it was meant to solve.
Call (763) 402-9301
Book a Camera Inspection
THREE TRIGGERS

Three Situations That Require Chimney Relining

Relining — installing a new liner inside an existing flue — applies to three specific situations.
1

A Camera Finds Liner Failure

Cracked clay tiles, offset joints, or through-wall breaches turn up on a camera inspection of the existing liner.

2

The Appliance Has Changed

Fuel type, BTU output, or vent category changed — and the original liner was sized for the previous system.

3

A Level 2 Finding Disqualifies It

A Level 2 inspection produces a written finding that disqualifies the existing liner from continued use.

Each trigger is different, but the repair is the same: a new liner installed inside the existing masonry flue, fitted to what the chimney needs to serve. Relining isn’t cosmetic — it replaces the structural pathway that contains combustion gases and directs them out of the home. When that pathway is compromised, the chimney looks fine from outside; the problem is entirely interior, and invisible without a camera.
This page covers relining as a replacement service — removing a failed or incompatible liner and installing a correctly sized one. If you need a liner in a chimney that never had one, or one being newly lined after a system addition, see the chimney liner installation page — the sizing basis, material selection, and code triggers differ between the two.
Sized to Appliance
BTU · Vent · Flue Height
Camera-Verified
Geometry Before Install
NFPA 211
Sizing Tables Followed
One Crew
Camera Through Documentation
THE MOST COMMON TRIGGER

Failed Clay Tile Liners in Older Minneapolis Construction

Clay tile liner failure — deterioration of segmented flue tiles in pre-1960 chimneys — is the most common relining trigger in this market.
Minneapolis has a high concentration of pre-1960 housing — craftsman bungalows, foursquares, and Tudor revivals from roughly 1905 through the 1950s overwhelmingly have clay tile liners, sized for the appliances of their day: wood-burning fireplaces and oil or coal furnaces running at high flue temperatures. (For how those original systems were built, see our resource page on chimneys in Minneapolis older homes.)
What accelerates failure specifically: flue-gas temperature dropped sharply when those homes converted to natural gas. Modern high-efficiency gas appliances run much cooler, and a cooler flue means more condensation inside the liner. That condensate is acidic, and over years it attacks the mortar between tile segments — producing offset joints, hairline cracks, and eventually through-wall breaches. None of it is visible from the firebox or rooftop; it only shows up under camera.
Minneapolis freeze-thaw cycling accelerates it further: water enters cracked tile joints in fall, freezes in winter, expands, and widens the breach. Each season advances the damage — and by the time a homeowner sees debris in the firebox, the liner has been deteriorating for seasons.
SIZING, NOT GUESSING

How Brian Levi Sizes a Replacement Liner

Every relining job starts with a sizing calculation — not an estimate.
Portrait of Brian Levi, founder of ChimTech
Brian Levi
Founder, ChimTech
I’ve seen what happens when a replacement liner is pulled from stock based on the original clay tile dimensions rather than the appliance it will serve. An oversized liner on a modern gas unit produces the same condensation problem that destroyed the original — you replace the material but not the cause.
The calculation takes three inputs: the appliance’s BTU output, the vent-connector size specified by the manufacturer, and the height of the flue. That gives a required cross-sectional area, which determines the liner diameter. Matching diameter to the connected appliance’s BTU and vent requirements is what separates a relining job that solves the problem from one that repeats it.
At ChimTech the sizing calculation is documented in the job record, so the homeowner has a permanent reference confirming the liner was sized to the appliance — not to whatever tile was in the flue before. NFPA 211, the national standard governing chimney system design, establishes the technical basis for these calculations; we work from those tables, and the documentation reflects it.
MATCH THE LINER TO THE APPLIANCE

The Liner You Install Has to Match the Appliance You're Running

Liner selection starts with appliance requirements, not with what’s easiest to source.

Stainless Steel Flex

A corrugated stainless liner threaded through the existing flue from the top — the most common solution for Minneapolis older homes, since it accommodates the offsets and irregularities typical of pre-1960 flue geometry.

Rigid Stainless Section

For straight-run chimneys where the flue geometry allows a rigid section rather than a flexible one.

Cast-In-Place

Poured or pumped to conform to the existing flue interior — for severely deteriorated or irregularly shaped flues where neither flex nor rigid stainless fits.

One factor matters on Minneapolis homes specifically: liner insulation. When the chimney runs along an exterior wall — common in older construction — the liner loses heat rapidly in winter, and a cold liner produces poor draft. Wrapping or packing insulation around the stainless liner on exterior runs brings flue-gas temperature back up to where draft performs correctly and condensation drops. On exterior chimneys here, insulation isn’t optional — it’s essential.
OUR STANDARD

ChimTech's Relining Standards and Materials

Liner materials rated for the appliance category — no substitutions based on availability.

Liner diameter calculated from appliance BTU output and manufacturer vent specs — not from original tile dimensions.

Material selection confirmed against the appliance's vent category (Category I through IV per NFPA 211).

Stainless steel gauge appropriate to the flue-gas temperature and the connected appliance type.

Liner insulation installed on exterior chimney runs where winter heat loss affects draft performance.

Top plate and cap fitted to seal the liner termination and protect against weather and debris entry.

Sizing calculation documented in the job record — appliance BTU output, flue height, and selected liner diameter.

No component is ordered before the sizing calculation is complete. No liner is installed before the flue geometry is confirmed by camera.
THE SEQUENCE

From Camera Assessment Through Completed Documentation

A defined three-part sequence built around the specific failure mode driving the project.
01

Liner Condition & Geometry Assessment

A camera inspection of the existing flue documents liner condition and the specific failure type — tile fractures, mortar deterioration, or offset breaches — and measures flue geometry to confirm whether offsets or obstructions affect liner selection. The footage is retained in the job record. If a system conversion is the trigger, the new appliance's vent requirements are confirmed before sizing begins.

02

Liner Selection, Sizing & Installation

Selection is finalized from the sizing calculation and geometry findings. On a stainless flex install, the liner is threaded from the rooftop through the flue, connected at the appliance below, seated at the top plate, and secured — with insulation installed on exterior runs before the top plate closes. ChimTech performs every component with its own crew: the crew that runs the camera installs the liner. No portion is subcontracted.

03

Continuity Check & Written Record

After installation we confirm liner continuity — no obstructions, no gaps at the connection points — and record the final installed diameter, material, and insulation spec. Where a Minneapolis mechanical permit is required, ChimTech files it directly. The homeowner receives the completed job record at the close of the visit, including the sizing-calculation inputs and any permit documentation.

WHERE WE RELINE

Where ChimTech Performs Chimney Relining in Minneapolis

ChimTech schedules relining across the Minneapolis neighborhoods where liner failure and appliance-conversion calls concentrate.
Relining calls follow the city’s pre-1960 housing distribution closely. The blocks generating the most work are Longfellow (55406) and Nokomis (55417), where foursquares with original clay tile liners are common on nearly every street, and the South Minneapolis corridors along Chicago and Nicollet, where oil-to-gas conversions over the past two decades have produced the most liner-incompatibility issues. Northeast Minneapolis (55413) generates frequent calls tied to fuel conversion in older rental stock, while Linden Hills (55410) and Kenwood calls are typically inspection-triggered.
That pattern repeats across Minneapolis zips 55406, 55407, 55408, 55409, 55410, 55413, and 55417. If your home is within Minneapolis city limits and the liner needs to be replaced, scheduling runs through the ChimTech office directly — not a regional call center — which means shorter lead times and the same technicians from camera inspection through final documentation.
LongfellowNokomisSouth MinneapolisNortheastLinden HillsKenwood
Call (763) 402-9301 to schedule a camera inspection and sizing consultation.

Book Your Minneapolis Chimney Relining Assessment

Schedule a camera inspection and sizing consultation. Have your appliance type and last inspection date ready — it helps us set the right scope for the first visit. If you’ve already had a Level 2 inspection with a written liner finding, bring that documentation; it’s exactly what we need to begin the sizing calculation and get the project moving. Prefer email? Reach us at office@chimtech.org.
Call (763) 402-9301
FAQ

Frequently Asked Questions — Chimney Relining

Relining replaces an existing liner that has failed or become incompatible with the connected appliance; liner installation adds a liner to a flue that either never had one or is being fitted for a newly added appliance. The distinction affects the sizing basis, the permit category, and in some cases material selection. Both involve a new liner inside the flue, but the starting condition and code triggers differ.

The determining factor is the scope and location of the damage found during camera inspection. Isolated mortar joint failures at accessible tile segments can sometimes be spot-patched; through-wall breaches, offset joints from settlement, and widespread tile fracturing across multiple sections require full relining. ChimTech documents the specific failure type and location during the camera inspection, so you have a written basis for that decision — not just a verbal recommendation.

When the new appliance has a different BTU output, vent-connector size, or vent category than the system it replaces, the existing liner may no longer be correctly sized. Most manufacturers specify liner requirements in their installation documentation, and Minneapolis mechanical code reflects them. If the numbers don’t match, relining is required before the new appliance can be connected and operated.

UL-listed stainless flex liners installed to the correct gauge for the appliance category are rated for the life of the appliance under normal operating conditions. Minneapolis freeze-thaw cycling doesn’t affect the liner directly once it’s inside the flue — the stainless isn’t exposed to the exterior. What affects longevity is correct sizing at installation: an oversized liner accumulates acidic condensate, and that’s what degrades stainless over time.

It depends on scope and connection to a mechanical system. Relining a flue serving a gas appliance — furnace, boiler, or water heater — typically requires a Minneapolis mechanical permit; relining a flue serving a wood-burning fireplace may not, depending on specifics. ChimTech reviews permit requirements for each project and files directly when one is required, and that documentation is included in the job record.

No. The existing liner is taken out of service at the start of the project, and during the installation window the connected appliance can’t operate. For most residential relining projects in Minneapolis the install is completed in a single visit, so the out-of-service period is limited to the project day. Scheduling before the heating season starts avoids timing conflicts with appliance dependence.
